The HCPL-3120-000E is a 2.5 Amp Output Current IGBT Gate Drive Optocoupler. The HCPL-3120-000E is ideally suited for driving power IGBTs and MOSFETs used in motor control inverter applications. The high operating voltage range of the output stage provides the drive voltages required by gate controlled devices. The applications of the HCPL-3120-000E are IGBT/MOSFET gate drive, AC/Brushless DC motor drives, Industrial inverters, Switch mode power supplies.
Parametrics
HCPL-3120-000E absolute maximum ratings: (1)Storage Temperature:-55 to 125℃; (2)Operating Temperature:-40 to 100℃; (3)Average Input Current:25mA ; (4)Peak Transient Input Current:1.0A(<1 μs pulse width, 300 pps); (5)High Peak Output Current:2.5A ; (6)Low Peak Output Current:2.5A ; (7)Supply Voltage:0 to 35Volts; (8)Input Current (Rise/Fall Time):500ns; (9)Output Voltage:0 to VCC; (10)Output Power Dissipation:250mW ; (11)Total Power Dissipation:295mW.
Features
HCPL-3120-000E features: (1)2.5 A maximum peak output current; (2)2.0 A minimum peak output current; (3)25 kV/μs minimum Common Mode Rejection (CMR) at VCM = 1500 V; (4)0.5V maximum low level output voltage (VOL) ; (5)Eliminates need for negative gate drive; (6)ICC = 5 mA maximum supply current; (7)Under Voltage Lock-Out protection(UVLO) with hysteresis; (8)Wide operating VCC range: 15 to 30 Volts; (9)500 ns maximum switching speeds; (10)Industrial temperature range: -40℃ to 100℃.
