Product Summary

P2Y0A21YKOF is a general purpose type distance measuring sensors. The devices in this publication are designed for use in general electronic equipment designs such as personal computers, office automation equipment, telecommunication equipment [terminal], test and measurement equipment, industrial control, audio visual equipment and consumer electronics. In details, it used in TVs, personal computers, cars and copiers.

Parametrics

Absolute Maximum Ratings:(1)Supply voltage, VCC: 0.3 to +7 V; (2)Output terminal voltage, VO: 0.3 to VCC +0.3 V; (3)Operating temperature, Topr: 10 to +60 °C; (4)Storage temperature, Tstg: 40 to +70°C.

Features

Features: (1)Less influence on the color of reflective objects, reflectivity; (2)Line-up of distance output/distance judgement type; (3)Distance output type (analog voltage) : GP2Y0A21YK; (4)Detecting distance : 10 to 80cm; (5)Distance judgement type : GP2Y0D21YK; (6)Judgement distance : 24cm(Adjustable within the range of 10 to 80cm [Optionally available]); (7)External control circuit is unnecessary; (8)Low cost.

Diagrams

GP2Y0A02YK
GP2Y0A02YK


SENSOR DIST MEASUR 150CM ANLG

Data Sheet

Negotiable
GP2Y0A02YK0F
GP2Y0A02YK0F

Sharp Microelectronics

Proximity Sensors Distance Measuring Sensor 20-150cm

Data Sheet

Negotiable
GP2Y0A21YK
GP2Y0A21YK


SENSOR DIST MEASUR 80CM ANLG

Data Sheet

Negotiable
GP2Y0A21YK0F
GP2Y0A21YK0F

Sharp Microelectronics

Proximity Sensors Distnc Measurng Snsr Wde Beam 10-80cm

Data Sheet

Negotiable
GP2Y0A700K0F
GP2Y0A700K0F

Sharp Microelectronics

Proximity Sensors DISTANCE MEASURING

Data Sheet

Negotiable
GP2Y0A710K0F
GP2Y0A710K0F

Other


Data Sheet

Negotiable
